Double Rod End Hydraulic Cylinder Inductive Feature With Sensor Switch

Product Categories

Dongguan Jiazheng Hydraulic Technology Co, LTD

Contact Now

Name: Double Rod End Hydraulic Cylinder Inductive Feature With Sensor Switch
Brand: Jiayan
Price: 1 USD

Brand Name : Jiayan

Model Number : SD/SW

Certification : ISO9001:2008

Place of Origin : Dongguan China

MOQ : 1 set

Price : Negotiable

Payment Terms : L/C, T/T, Western Union ,Paypal

Supply Ability : 400 sets per week

Delivery Time : 8 days

Packaging Details : poly bag and carton box

Material : Carbon Steel

Mounting Type : Axial end rod type

Max. Bore of Cylinder : 80mm

Max Standard Stroke : 50mm

Sensor Switch : available

Warranty : 1 year (change new one for free)

Contact Now

Single End Rod and Double End Rod Type Push Pull Inductive Hydraulic Cylinder With Sensor Switch

ORDERING Code

CHTM - SD 32 20 N S1

1 2 3 4 5 6

1	Series	CHTM
2	Mounting type	SD:Axial Single end rod type SW:Axial Double end rod type
3	Bore of Cylinder	Φ32 , Φ40 , Φ50 , Φ63 , Φ80
4	Standard stroke	10,20,30,40,50
5	Rod end type	N: Female thread N W:Male thread W
6	Sensor switch	1Pcs of S1, 2Pcs of S2 Voltage DC 4-24V AC4-120V Currency 5-40mA

Double Rod End Hydraulic Cylinder Inductive Feature With Sensor Switch

CHTM Hydraulic magnetic type SD & SW.

Double Rod End Hydraulic Cylinder Inductive Feature With Sensor Switch
