Name: Adjustable Hydraulic Control Valve 12 Volt Hydraulic Sequence Control Valves Check Valve
Brand: Jiayan
Price: 1 USD

Brand Name : Jiayan

Model Number : CLH

Certification : ISO9001:2008

Place of Origin : Dongguan China

MOQ : 1 set

Price : Negotiable

Payment Terms : L/C, T/T, Western Union, PayPal

Supply Ability : 400 sets per week

Delivery Time : 7 days

Packaging Details : poly bag and carton box

Material : Carbon Steel

Adjustable Pressure Range : 5.0~18.0 MPa

Operating pressure range : 6.0~35.0 MPa

Starting Pressure : 0.01 MPa

Operating temperature °C : 0~70°C

fluid : hydraulic oil equivalent to ISO-VG-32

Warranty : 1 year (change new one for free)

Contact Now

Hydraulic Sequence Valve High Operation Pressure Simple Installation Carbon Steel Body

SPECIFICATION

Model No.	CLG-3A	CLG-6A
Adjustable pressure range MPa	1.0~6.0	5.0~18.0
Operating pressure range MPa	2.0~35.0	6.0~35.0
Adjustable screw pressure change value MPa/Rev	1.0	2.8
Starting pressure MPa	0.01
Operating temperature °C	0~70°C
Useable fluid	hydraulic oil equivalent to ISO-VG-32

Note:

Excessive side oil supply can sometimes result in inaccurate sequential actions.

Install a flow control valve with a built-in check valve in front of the oil hole or

execute flow control on the oil pressure source.

Ordering Code:

CLG - 3 A(5.0MPa)

1 2 3 4

1	Series	CLG
2	adjustable pressure range	3: 1.0~6.0 MPa 6: 5.0~18.0MPa
3	A	Manifold type
4	Pre-set pressure (Set pressure value for sequence operation)	Provide a difference of more than 1MPa between operating and setting pressure. When using multiple CLG sequence valves in a parallel fashion, provide each set pressure with a pressure difference more than 1MPa.
